Description
MeshPoint
Mechanical
Dimensions 99.5 x 97.8 x 33.1 mm (3.9 x 3.9 x 1.3″)
Weight 215 g (7.6 oz)
Hardware
Networking Interface WiFi
(1) GbE RJ45 LAN
Max. Power Consumption 9W
ESD/EMP Protection ± 24kV Air/Contact
Max. TX Power 22 dBm
Speeds
2.4 GHz
5 GHz
300 Mbps
867 Mbps
MIMO
2.4 GHz
5 GHz
2×2
2×2
Antennas (1) Dual-Band Antenna, Single-Polarity
Buttons Reset
Operating Temperature -10 to 55° C (14 to 131° F)
Operating Humidity 5 to 95% Noncondensing
Certifications FCC, CE, IC
NDAA Compliant Yes
Software
WiFi Standards 802.11ac
Power Save Supported
Wireless Security WPA2-PSK AES/TKIP
Supported Data Rates (Mbps) – for both devices
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
802.11ac 13 Mbps to 866.7 Mbps (MCS0 – MCS9, VHT 20/40/80)
Router
Mechanical
Dimensions 99.5 x 97.8 x 99.6 mm (3.9 x 3.9 x 3.9″)
Weight 410 g (14.5 oz)
Hardware
Networking Interface WiFi
(1) GbE RJ45 WAN
(4) GbE RJ45 LAN
Max. Power Consumption 11W
ESD/EMP Protection ± 24kV Air/Contact
Max. TX Power 26 dBm
Radios 2
MIMO Chains 6
Speed 1750 Mbps
Antennas (1) Dual-Band Antenna, Tri-Polarity
Display 40.6 mm (1.6″) Diagonal, 240 x 240, 212 ppi, G+F Touch, Full Color
Buttons Reset
Operating Temperature -10 to 55° C (14 to 131° F)
Operating Humidity 5 to 95% Noncondensing
Certifications FCC, CE, IC
Software
WiFi Standards 802.11ac
Power Save Supported
Wireless Security WPA2-PSK AES/TKIP
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40)
802.11ac 13 Mbps to 1300 Mbps (MCS0 – MCS9, VHT 20/40/80)
